Blackmagic Design High definition live production switcher packed with advanced features - 10x 3G‑SDI inputs - 6x 3G‑SDI aux ou

CARATTERISTICHE

Switcher di produzione live ad alta definizione ricco di funzioni avanzate. Il design con un banco effetti M/E include 10 ingressi 3G-SDI con conversione di standard e 6 uscite aux 3G-SDI indipendenti. Inoltre offre un’uscita webcam USB, DVE, chiavi cromatiche, media player, multiview e molto altro.

SPECIFICHE

• • Total Video Inputs: 10
  • Total Video Outputs: 6
  • SDI Rates: 1.5G, 3G
  • Total Audio Inputs: 2 x balanced 1/4 inch Jack, 1 x 5 pin XLR Talkback.
  • Total Audio Outputs: 1 x 5 pin XLR Talkback.
  • SDI Audio Inputs: 2 Ch embedded audio on all SDI inputs.
  • SDI Audio Outputs: 2 Ch embedded audio on all SDI outputs.
  • Timecode Connections: None
  • Reference Input: Tri-Sync or Black Burst.
  • Video Input Re-Sync: On all 10 inputs.
  • Frame Rate and Format Converters: On all 10 inputs.
  • SDI Aux Outputs: Any of the 6 SDI outputs.
  • SDI Preview Outputs: Any of the 6 SDI outputs.
  • SDI Program Outputs: Any of the 6 SDI outputs.
  • Down Converted SDI Program Output: None
  • Webcam Output: 1 x USB-C supporting 720p or 1080p at PGM frame rate.
  • Total Multi Views: 1 x 3G-SDI
  • Control Panel Connection: Ethernet. Direct connection between panel and chassis, or via network.
  • Internal Timecode Generator: Yes
  • Talkback: RJ45 for 3rd party talkback systems.
  • Tally Output: Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included).
  • Ethernet: Supports 10/100/1000 BASE-T.
  • Computer Interface: 1 x USB-C supports USB 3.1 Gen 1 (5Gb/s)
